依客思BNG 防爆挠性连接管绕线钢丝编织金属橡胶型一内一外丝4分6穿过线软管
详细信息
| | 品牌：依客思 | | 型号：BNG | | 加工定制：是 | |
| | 材质：橡胶护套、钢丝编织、304不锈钢� | | 尺寸：G3/4 | | 重量：5KG | |
| | 适用范围：广泛用于石油开采、炼油、化工、 | | | | | |
防爆挠性连接管适用于可燃性粉尘环境20区、21区、22区以及ⅡBⅡC级T1-T6组爆炸性混合物场所，作为防爆电器设备的进出线连接或钢管布线弯曲难度较大的场所连接之用。防爆挠性管结构软管两端为金属螺纹活接头，管体部分由金属软管，外层夹布优质橡胶和增强尼布软管护套以及夹层钢丝编织网管三种形式组成。本产品具有耐燃、耐油、耐腐蚀、耐水、耐磨、耐老化、挠性良好、结构牢固、工作可靠等优点，一般有500，700，1000等长度。
1：防爆挠性连接管绕线钢丝编织金属橡胶型一内一外丝4分6穿过线软管
2：橡胶护套防爆软管NGd-DN50 DN70 DN80 DN100 防爆挠性连接管
适用范围:
1.适用于1区、2区危险场所;
2.适用于ⅡA、ⅡB类爆炸性气体环境;
3.适用于可燃性粉尘环境20区、21区、22区;
4.适用于爆炸性气体混合温度:T1~T4;
5.广泛用于石油开采、练油、化工、军工等危险环境及海洋石油平台、油轮等危险场所工作及场景照明之用;
pvc护套防爆挠性连接管
橡胶管防爆挠性连接管
不锈钢防爆挠性连接管
塑料防爆挠性连接管
产品特点:
1、具有耐燃、耐腐蚀、耐水、耐老化、挠性良好、结构牢固、工作可靠等优点。
2、挠性管长度,螺纹尺寸可根据用户需要特殊加工。如NPT螺纹,公制螺纹等。注:标注螺纹规格时应注明内外螺纹。
如:BNG-700×G3/4(内)/G1(外)意义为长度为700,一端为内螺纹G3/4,一端为外螺纹G1的橡胶护套挠性连接管。
3、符合GB3836-2000，IEC60079标准要求
购买须知
■ 标注螺纹规格时应注明内外螺纹,如NGdⅡ-1000×G3/4"(内)/G"(外),即长度为1000mm,一端为G3/4"内螺纹,另一端为G1"外螺纹的防爆挠性连接管
Explosion-proof flexible connection pipe is suitable for flammable dust environment 20,21,22 zones and IIBIIC class T1-T6 Group explosive mixture site, it is used for connecting the entrance and exit lines of explosion-proof electrical equipment or places where the wiring of steel pipes is difficult to bend. The two ends of the flameproof flexible tube structure hose are metal thread joint, the tube body is composed of metal hose, high-quality rubber and reinforced nib hose jacket, and sandwich steel wire braided net pipe. This product has fire-resistant, oil-resistant, corrosion-resistant, water-resistant, wear-resistant, aging-resistant, flexible, solid structure, reliable work and other advantages, generally 500,700,1000 length. Scope: 1. Apply to Area
1 and Area 2 dangerous places.
- Suitable for IIA, IIB explosive gas environment;
- 3. Suitable for combustible dust environment in 20,21 and 22 zones.
- 4. Suitable for explosive gas mixing temperature: T 1 ~ T 4; 5. Widely used in oil exploitation, oil refining, chemical, military and other dangerous environment and offshore oil platforms, tankers and other dangerous places for work and scene lighting purposes; Rubber tube explosion-proof flexible connecting pipe, stainless steel explosion-proof flexible connecting pipe, plastic explosion-proof flexible connecting pipe, features: 1, with fire-resistant, corrosion-resistant, water-resistant, anti-aging, good flexibility, solid structure, reliable and other advantages. 2, flexible tube length, thread size can be according to the needs of special processing. NPT thread, metric thread, etc. . Note: internal and external threads should be noted when marking thread specifications. For example: BNG-700 × G 3/4(inside)/g 1(outside) means a rubber sheathed flexible connecting pipe with length of 700, one end of internal thread G 3/4 and one end of external thread G 1. 3. Meet the requirements of GB3836-2000, IEC 60079. When purchasing and marking thread specifications, it should indicate internal and external threads, such as NGdII-1000 × g 3/4”(internal)/g”(external) , i. e. length of 1000mm, g3/4” internal thread at one end and G1” external thread at the other end
